Pst / comtech ARD8829-100 amplifier, 0.8 - 2 ghz, 100W
PST / Comtech ARD8829-100 Amplifier, 800 MHz - 2 GHz, 100 Watt
The Comtech ARD8829-100 is an RF Amplifier with a frequency of 0.8 to 2 GHz and power of 100 Watts with GPIB connectivity. The Comtech PST ARD8829-100 is the GPIB version of the standard AR8829-100 model. The 8829-100 amplifier is a rack-mountable unit which incorporate the Series AM amplifier in a cabinet containing a built-in universal AC power supply. It is forced-air cooled by blowers built into the mechanical package. This AR model has optional IEEE BUS (GPIB) for remote control and monitoring.
Features of the PST / Comtech ARD8829-100 Amplifier include:
* Frequency Range: 800 MHz to 2.0 GHz
* Input Overdrive: 10 dB above 1 dB compression
* RF Input Signals: CW, FM, AM, and pulse/phase modulation
* Load VSWR: Open / Short Circuit Protected, Unconditionally Stable
* Noise Figure: 10dB Typical
* maximum RF Input: 10dBc above the input required to achieve P1dB
* RF Connectors, Type N Female
This amplifier has been tested and is in good condition
*NOTE THAT THIS AMPLIFIER WAS PRIVATE LABELED AS SCIENTIFIC POWER SYSTEMS BY PST / COMTECH
****30-DAY WARRANTY INCLUDED***
Unit is available for RENTAL - Call (***) 806-6600 if you would like to RENT this item.
