250 ton 16" strk pressmaster 250T-e/h h-frame hydraulic
250 Ton 16" Strk Pressmaster 250T-E/H H-FRAME HYDRAULIC
250 Ton 16" Stroke Pressmaster 250T-E/H H-FRAME HYDRAULIC PRESS, Electric Over Hydraulic
250 TON PRESSMASTER H-FRAME PRESS
RATED CAPACITY, TONNAGE........................... 250
STROKE............................................ 16"
BORE.............................................. 12"
RAM SPEED (seconds/Inch) ADVANCE ................. 16
RAM SPEED (Seconds/Inch) RETURN .................. 19
DISTANCE BETWEEN POSTS (RIGHT TO LEFT)............ 48"
MAXIMUM DISTANCE FROM BED TO RAM ................. 31"
OVERALL HEIGHT ................................... 95"
OVERALL WIDTH .................................... 76"
OVERALL DEPTH .................................... 58"
WEIGHT ........................................... 6,900#
DOUBLE-ACTION PERMITS PULLING AS WELL AS PRESSING RAM ACTION
SPEED CONTROL - ALLOWS OPERATOR TO SET THE PROPER SPEED FOR THE TASK.
PRESSURE REGULATOR - TO LIMIT RAM PRESSURE
OPEN SIDES TO FACILITATE WORK ON LONG PIECES
SAFETY VALVE FOR OVERLOAD PROTECTION
FLAT RAM NOSE TO ALLOW USER TO ADAPT THE PRESS TO A SPECIFIC JOB.
BALDOR 20 HP, 208/230/460 VOLT MOTOR
