Anilam wizard 450 key board
The Video Game Repair Professionals
A job clock is included for timing. Wizard 450 comes with the popular ANILAM interactive message display, operating like a setup wizard byn prompting for inputs. It will calculate and display feed-rate, a unique and highly appreciated feature.
EverTrack- Additional precision grating on the RBS and RBM linear encoders ensure permanent position tracking. The position will never be lost due to power interruptions.
Radius/Diameter Mode- The console can display the position either as a radius or diameter, an invaluable feature for
Machine Error Compensation- Machine mechanics are never exact. A correction factor can be set for each axis independently. Just move the axis a known distance, input what it should have been and the wizard will automatically make the necessary correction. Correction is linear in Wizard 211 and can vary over four segments in other models.
Absolute/Incremental Mode- This feature allows positioning using either an absolute datum or the last position as reference for subsequent moves. Selectable with a single key stroke.
Interactive Message Display- The Wizard will calculate actual feed-rate and display here, or the job clock can be read. Also in this display, the Wizard will prompt for data input, making the most demanding operations easy to set up. With the built in help utility, the Wizard will tell the operator what the proper F-codes are.
Bolthole Patterns- Bolthole patterns are often symmetric. The Wizard 450 will automatically calculate all the positions for circular, linear, array or frame patterns, from a minimum of data entry. Only the centerpoint, diameter and number of holes are required for a full circular hole pattern with up to 360 holes.
Tool Length Offsets- The Wizard 450L will keep track of tool length offsets, so there is no need to redatum tools.
Axis Coupling- When there are two slides on the same axis, the Wizard 450L will couple the two positions
together. The operator can use the slides independently and the Wizard 450L will automatically calculate the true tool position.
Display resolution- .0005/.0001/.0002/.0005/.001 inch
Machine error compensation- 4-piont lin.
Approaching zero warning- selectable
Linear/Array bolthole patterns (10)- 999 holes
Frame bolthole patterns (10)- 999 holes
Circular bolthole patterns (10) (full or partial)- 360 holes
