Agilent hp E6000C sm mm fiber otdr w E6012A E6005A 41DB
* Agilent E6000C OTDR Mainfame
* Option: 003 Color Screen
* Agilent E6012A SinlgeMode Module
* Agilent E6091A OTDR ToolKit II Plus
* Agilent OTDR & Fiber Breaker Locator Support CD-ROM
Agilent HP E6000C Mini-OTDR With E6012A Singlemode 1500nm & 1625nm And E6005A Multimode 850nm & 1300nm Modules
Long Haul Singlemode OTDR Module!
Complete With Full Accessories & Carrying Case!
The Agilent Mini-OTDR is the best selling product in Agilent's portfolio of Optical Network Test Solutions for the installation, maintenance and operation of fiber networks.
The Mini-OTDR is designed to provide its users with the fastest tool available for installing and commissioning multiple fiber links and locating faults for fiber maintenance. This is accomplished through high measurement performance and an award winning simple user interface.
Fiber Break Locator to quickly find breaks and bends.
Locate and characterize splice and connector losses.
Multifiber testing for fast high-count cable qualification.
Perform power and loss measurement with the built-in light source and the power meter module.
Graphical representation of measurement results in event tables, showing loss and reflection, and pass/fail results.
Visual Fault Finder to check patch cords for light leakage.
* 0 km to 400 km Span: 0.1 km to 400 km
* Minimum sample spacing: 4 cm
* Refractive index: 1.00000 to 2.00000
* Length unit: km, ft, or miles
* Measurement points: up to 64000
* 0.1 to 10.0 dB/Div Read-out resolution: 0.001 dB
* Reflectance range: 14 dB to 60 dB
* Backscatter coefficient: 10 to 70 dB at 1 s
* You can select any of the following pulsewidths: 10 ns, 30 ns, 100 ns, 300 ns, 1 s, 3 s, and 10 s (all modules). You can also select 5 ns for E6003C, 5A, 9A modules, and 20 s for E6003B, E6003C, E6008B, and E6013A.
* With the E6005A module, you can select a pulsewidth from 5 ns to 100 ns at 850 nm, and from 5 ns to 10 s at 1300 nm.
* With the E6009A module, you can select a pulsewidth from 5 ns to 100 ns at 850 nm, and from 5 ns to 1 s at 1300 nm.
* 3.5 floppy disk drive: for high density 720/1440 kByte floppy disks. MS-DOS format compatible. Reduced operating temperature of 5C to 45C, with 35% to 80% humidity at 40C. Memory Card: PCMCIA Type II. 440 MB with up to 13000 traces (typical with 64000 data points).
* Internal memory: SRAM up to 2 MB. Up to 300 traces (typical) with 4000 data points
* Trace format: compliant to the following Bellcore/Telcordia OTDR trace formats:
* Trace Information: 5 comment labels of up to 15 alphanumeric characters, and 5 comment fields of up to 41 alphanumeric characters are provided for each trace.
* Reflective and nonreflective. Maximum number of events: 100.
* Threshold for non-reflective events: 0.0 to 5.0 dB, selectable in 0.01 dB steps.
* Threshold for reflective events: - 14.0 to ?65.0 dB, selectable in 0.1 dB steps.
* Threshold for fiber breaks: 0.1 to 10 dB, selectable in 0.1 dB steps.
* Fiber End Threshold: 0.1 to 20 dB, selectable in 0.1 dB steps.
* Display Color or monochrome VGA-LCD: 18.3 cm (7.2?)
* Display points: 640 x 480 Points
* Measurement update rate: two measurements per second in refresh mode
* RS232C: Maximum transmission rate: 115200 bps Transmission time at 115200 bps for trace data: 4000 points at approx. 1 second; 64000 points at approx. 4 seconds.
* Centronics: Standard parallel port (SPP).
* Keyboard: PS2 (Min-DIN). For English Standard, PS2, or AT keyboard.
* Instrument settings: storage and recall of user-selectable instrument settings.
* Laser safety class: All OTDR laser sources specified by this data sheet are classified as Class 1M according to IEC 60825-1 (2001).
* The Visual Fault Finder Sub-Module E6007A complies with Class 2 according to IEC 60825-1 (2001).
* All laser sources comply with 21 CFR 1040.10 except for deviations pursuant to Laser Notice No. 50, dated 2001-July-26
* Automatic Multi Fiber Test
* Power Meter / Loss Test mode 1
* Visual Fault Finder mode 1
* Operating Temperature: 0 to 50 degees C Storage Temperature: 40 to +60 degrees C
* Humidity: 95% R.H from 0 to 40 degrees C
* External Battery: NiMHtypically 8 hours continuous operation (minimum 4 hours) with Option #006. Charging time < 3 hours, non-operating
1550 nm 25 nm/1625 nm 20 nm
850 nm 30 nm/1300 nm 30 nm
