Honeywell T7300A1005 7-day programmable thermostat
Honeywell T7300A1005, T7300A 1005
Ambient: 40 F to 110 F (4 C to 43 C).
Display Accuracy: 1 F ( 1 C).
Range: 45 F to 95 F (7 C to 35 C).
One model can be used for single-stage and multistage applications.
7-day programming two occupied/unoccupied periods per day.
Individual temperature setpoints for: Occupied heat and cool. Unoccupied heat and cool.
Proportional plus integral control eliminates temperature fluctuations and thermostat tampering.
Intelligent Recovery automatically optimizes start time depending on building load.
Intelligent Fan energizes fan on call for heating or cooling only. Fan can be configured to run continuously in occupied mode.
Automatic heat/cool changeover.
Universal Versaguard Thermostat Guard available for T7200 and T7300/Q7300.
Locking setpoints and schedules eliminate tampering (use keyboard security).
One thermostat can be used for heat pump or conventional control.
Configurable to vary fan and reversing valve operation.
Use with Q7300 to interface with C7400/W7459 Economizer System for total integration of rooftop control.
Convenient overrides allow temporary changes.
Battery backup saves program and maintains clock time during power failure.
Auxiliary contacts available for use with economizer.
Obsolete - suggested functional replacement T7351F2010. 2ET04700224 YORK DIRECT 2ET04700324 YORK DIRECT 2ET04700424 YORK DIRECT Y7300A1000 HONEYWELL FUNCTIONAL Y7300A1018 HONEYWELL FUNCTIONAL Y7300C1014 HONEYWELL FUNCTIONAL
