1997 supertec G30P-60C universal id/od grinder
1997 SUPERTEC G30P-60C UNIVERSAL ID/OD GRINDER
12" X 24" SUPERTEC "PRECISION" UNIVERSAL I.D./O.D.
(ALSO COMES WITH OVER-THE-WHEEL DRESSER)
W/MITSUBISHI PLC CONTROLLER FOR AUTO INFEED OF WHEELHEAD
MODEL: G30P-60C S/N: G-39703 NEW: APRIL 1997
SWING .......................................... 12"
DISTANCE BETWEEN CENTERS ....................... 24
MAX. WORKPIECE WEIGHT .......................... 330 LBS.
HYD. TABLE TRAVERSE, INF. VARIABLE .......... 2" TO 275" IPM
SWIVEL TABLE GRADUATED ...................... +/- 9 DEGREES
HANDWHEEL GRAD. ................................ 0.0002"
INFEED PER REV. OF HANDWHEEL ................... 0.1"
STD WHEEL SPEED ............................... 1650 RPM
WHEEL SIZE (DIA. X WIDTH X BORE) ...... 16" X 1" TO 2" X 5"
WHEELHEAD MOTOR ................................ 5 HP
MAX. INFEED TRAVEL ............................. 9.6"
HAND FEED TRAVEL ............................... 7.6"
TOP SLIDE TRAVEL ............................... 7"
POWER RAPID WHEELHEAD STROKE ................... 1.75"
AUTOMATIC WHEELHEAD INFEED (ON DIA.) .... 0.0001" TO .0999"
AUTO PLUNGE FEED RATE .......................... YES
WORKHEAD SWIVELS (LEFT & RIGHT) .............. 90 DEG. CCW
WORKHEAD SPINDLE SPEEDS ...................... 20 TO 920 RPM
WORKHEAD CENTER TAPER . ......................... #4 MT
WORKHEAD MOTOR .................................. 2 HP
QUILL TRAVEL ..................................... 1"
SPINDLE TAPER ................................... #4 MT
APPROXIMATE WEIGHT .......................... 8,580 LBS
APPROXIMATE FLOOR SPACE FOR OPERATION ...... 109"L X 90"W
MITSUBISHI PROGRAMMABLE AUTO INFEED CONTROL (PLC)
W/MULTI-LINEDISPLAY, BALL SCREW & SERVO MOTOR DRIVE:
-AUTO INFEED @ TABLE REVERSALS
-AUTO PLUNGE FEED (DUAL RATE - COARSE & FINE FEED SELECTION)
-WHEELHEAD RETRACTS TO ORIGINAL POSITION AUTOMATICALLY
AFTER CYCLE COMPLETION OF GRIND CYCLE
-AUTO TABLE PARK (LEFT OR RIGHT) @ COMPLETION OF CYCLE
HYDRASTATIC WHEELHEAD BEARINGS
CARRIAGE AND WHEELHEAD WAYS ARE AUTO LUBRICATED
MACHINE MOTORS ARE WIRED FOR 3/60/230-460 VOLT OPERATION
SWING DOWN INTERNAL GRINDING ATTACHEMENT WITH I.D. SPINDLE
COOLANT SYSTEM WITH PAPER FILTRATION
SONY "MILLMAN" 2-AXIS DIGITAL READOUT DISPLAY
ANGLE DRESSER (MOUNTS ON TABLE)
* * NEARLY LIKE NEW CONDITION & APPEARANCE * *
