> 10" swg 20" cc landis 1R od grinder, full auto cycle &
10" swg 20" cc landis 1R od grinder, full auto cycle &
10" Swg 20" cc Landis 1R OD GRINDER, FULL AUTO CYCLE &
10" Swing 20" Centers Landis 1R OD GRINDER, FULL AUTO CYCLE & "MICROFEED" OPTION
** LANDIS "MICROFEED" OPTION **
MODEL: 1R S/N: 884-93 NEW: 1982
WHEEL SIZE ................................ 16" DIAMETER
MAXIMUM WIDTH, FULL WHEEL ........................... 3"
WORK DIAMETER REDUCTION PER REVOLUTION OF
HANDWHEEL ....................................... 0.100"
FINE FEED KNOB .................................. 0.001"
WHEELHEAD MOTOR ................................... 3 HP
APPROXIMATE WEIGHT ........................... 4,150 LBS
APPROXIMATE DIMENSIONS .............. 78"L X 60"W X 60"H
ELECTRICAL CABINET DIMS. .......... 17"W x 42" DEEP x 76"H
LANDIS "MICROFEED" OPTION ... ALLOWS FOR FINER FINISH FEED
DUAL "LIVE" & "DEAD" WORKHEAD SPINDLE
HARD FILM MICROSHERE WHEEL SPINDLE BEARINGS
CARRIAGE AND WHEELHEAD WAYS ARE AUTOMATICALLY LUBRICATED
WHEELHEAD MOTOR IS 5 H.P./3/60/208-220-440 VOLT
SEPERATE ELECTRICAL CABINET, GET'S PLACED ON RIGHT SIDE OF
MACHINE (TAILSTOCK SIDE). DOOR ON SIDE OF UNIT OPENS 36".
