Corning siecor fuselite fiber termination systm cleaver
* Siecor P/N: 2812047-01 Crimp Tool
* Siecor P/N: 2812003-01 Crimp Tool
* Siecor P/N:214094-01 Bench Clamp
* Siecor FBC-006 Fiber Cleaver With Manual
* Siecor Fiber - Fiber Stage
* Siecor P/N: 2812052-01 Connector Strip Length Guage
* (2) Siecor P/N: 2812011-01 Connector Strip Length Guage
* (4) Siecor P/N: 95-200-45 SM-SC Connectors
* Clauss No-Nix Fiber Stripper
* Miller Fiber Optic Stripper
* (3) Flathead Screw Drivers
* Norton Crocus K624 Sanding Sheet
Corning Siecor FuseLite Fiber Optic Termination System Kit with FBC-006 High Precision Fiber Cleaver
Includes Carrying Case And Full Assessories!
The FuseLite Termination System, terminates optical fibers by fusion splicing to a prestubbed, factory-polished connector. This innovative combination of connector and fusion splicing technology provides a fast, user-friendly solution for high-performance optical fiber termination. The FuseLite Connector is a near-zero-length pigtail allowing field installation by fusion splicing to the field fiber within the physical boundaries of the connector. The stub fiber installed in the FuseLite Connector is polished in the factory, which eliminates the need for field polishing, increases the quality of the termination, and greatly reduces connector installation time. Single-mode connector options are FC, ST Compatible, and SC, as well as angled FC and angled SC.
* Insertion Loss 0.35 dB typical
* Reflectance Ultra PC: -55 dB
* Durability dB 0.3 dB; 200 insertions
* Temperature Cycling dB 0.2 dB; -40 to +75 C
* Tensile Strength 10 lb with 2.9 mm cable
* Fiber Alignment Automatic fiber positioning and ferrule alignment
* Typical Splice Loss < 0.15 dB mean (splice only)
* Splice Programs (3 fixed, 10 user defined)
* Operating Temperature -5 to +45 C
