16" w 12" h doall c-70 horizontal band saw, fully autom
16" W 12" H DoAll C-70 HORIZONTAL BAND SAW, FULLY AUTOM
16" Width 12" Height DoAll C-70 HORIZONTAL BAND SAW, FULLY AUTOMATIC
12" x 16" DOALL HORIZONTAL BAND SAW MODEL: C-70
ROUNDS............................. 12-3/4" DIAMETER
FLATS.............................. 12" x 16"
VARIABLE BAND SPEEDS................. 60 to 350 FPM
WHEEL DIAMETER....................... 16"
LOAD CPACITY......................... 4,000 LBS.
MAX. STOCK INDEX AT SINGLE STROKE.... 24"
HEIGHT OF HYDRAULIC VISES............ 6-1/4"
APPROX. WEIGHT....................... 5,000 LBS.
- 6' HYDRAULICALLY CONTROLLED FULLY AUTOMATIC
SHUTTLE-TYPE BAR FEED PREMITTING STOCK INDEXING OF
- HYDRAULICALLY CONTROLLED INFINITELY VARIABLE BLADE SPEEDS
- COUNTER ASSEMBLY TO BE SET FOR THE NUMBER OF PIECES OF
BE SAWED UP TO 9.999. IT WILL AUTOMATICALLY STOP SAW
- WORK HEIGHT SELECTOR DIAL TO SET CLEARANCE BETWEEN TOP
OF WORKPIECE AND BOTTOMOF BLADE
- STOCK INDEX SCALE GRADUATED FROM 0 TO 24" ON SIDE OF
- MANUAL WORK LIFT ROLLER AT END OF INDEX TABLE
- 5 HP 3/60/230-460 VOLT COMBINATION BLADE DRIVE &
