> 60" chk 100HP spdl mattison 36-60 rotary surface grinde
60" chk 100HP spdl mattison 36-60 rotary surface grinde
60" Chk 100HP Spdl Mattison 36-60 ROTARY SURFACE GRINDE
60" Chuck 100HP Spindle Mattison 36-60 ROTARY SURFACE GRINDER, 30" HEIGHT, HEAVY MACHINE (65,000 L
60" MATTISON "HEAVY DUTY" ROTARY SURFACE GRINDER
MODEL: 36-60 S/N: 60-619 NEW: 1968
CHUCK DIAMETER...................... 60"
MAXIMUM SWING....................... 80"
HEIGHT UNDER NEW WHEEL.............. 30"
TABLE SPEEDS........................ 1.6, 5.5, 10, 17 RPM
AUTOMATIC DOWNFEED, VARIABLE........ .005 TO .165
DIAMETER OF CORTLAND CHUCK.......... 36"
DIMENSIONS ........................ 196"L X 134"W X 174"H
APPROX. WEIGHT .................... 65,000 LBS
60" ELECTRO-MAGNETIC CHUCK (9/16" TO 5/8" CHUCK LIFE)
PENDANT CONTROL FOR MACHINE'S OPERATION
"TRABON" AUTOMATIC LUBRICATION SYSTEM
TWO-TIER, WATERFALL COOLANT SYSTEM
CATWALK AROUND BACK OF MACHINE
100 H.P., 220-440 VOLT, 3 PHASE 60 CYCLE SPINDLE MOTOR
(ONE TRUCK FOR MACHINE TOOL, OTHER TRUCK FOR ANCILLIARY EQUIPMENT)
Machine Location: WILMINGTON, DE
