Classt t-amp TA2024 audio amplifier board smt 2X15 watt
T-AMP TA2024 Audio Amplifier Board SMT 2X15 Watt
- 100% Brand New T-AMP TA2024 Audio Amplifier Board SMT 2X15 Watt
- Proprietary Digital Power Processing Technology
- Requires single +12V power source
- Output Power (per channel @ VS = 12V):
15W per channel (4 , 10% THD+N
10W per channel (4 0.1%, THD+N)
- Easy engineering evaluation platform for Tripath Technology s TA2024C product
- "Audiophile performance typically:
- Efficiency - >88% @ full power (RL = 8 )
- No heat sink required up to 15W per channel
- Turn-on & turn-off pop suppression
- Intelligent short-circuit protection
- Intelligent over-temperature protection
- Connects to any passive 4/8 speakers
- Takes standard audio line output from any sound system
- Cost-effective 2-layer PCB design
- GND should be connected to GND or the housing of your instrument.
- There are two audio-input methods. One is via audio input. Another is via terminals (J2, J5).
- There are two audio-output methods. One is via terminals (J3and J9). Another is via corresponding banana jack.
- 1 x T-AMP TA2024 Audio Amplifier Board SMT 2X15 Watt
