Maxim max 9790 9790AE MAX9790AE ev kit 32PIN tqfn ic
Model: MAX9789AE / MAX9790AE (Evaluation Kit)
Pin Packing: 32pin TQFN
The MAX9789A evaluation kit (EV kit) is a fully assembled and tested circuit board that evaluates the MAX9789A IC. The MAX9789A combines a stereo 2W Class AB speaker power amplifier, a stereo 85mW DirectDrive headphone amplifier, and a 120mA low-dropout (LDO) linear regulator in a single device. The MAX9789A is designed for use with the Windows Vista operating system and is fully compliant with Microsoft's premium mobile Vista specifications.
The MAX9789A provides separate stereo speaker and headphone amplifier inputs. Control pins provide independent shutdown of the speaker and headphone amplifiers, allowing speaker and headphone amplifiers to reproduce separate audio streams simultaneously.
The MAX9789A features an internal 120mA LDO. The LDO output voltage is internally set at 4.75V, or can be externally adjusted between 1.21V and 4.75V using a simple resistor-divider. The LDO can be enabled independently of the audio amplifiers.
The MAX9789A EV kit can be used to evaluate the MAX9790A. See the Evaluating the MAX9790A section for more details.
