18" thrt 20" h marvel MV460PC vertical band saw, pcii p
18" Thrt 20" H Marvel MV460PC VERTICAL BAND SAW, PCII P
18" Throat 20" Height Marvel MV460PC VERTICAL BAND SAW, PCII Prog Cntrl for Feed & Tilt,7-1/2HP,1-
MARVEL TILT FRAME VERTICAL BAND SAW,
MODEL MV460 PC, S/N MV-46010192PC, NEW 1997
CAPACITY AT 90 DEGREES .................... 18" X 20"
BLADE AT 45 DEGREES ....................... 18" X 15"
BLADE SPEED RANGE (INF VAR) ............... 60 - 340 FPM
FEED FORCE ................................ 0 -300 LBS.
BLADE LENGTH AND WIDTH .................... 1-1/4" x .042" x15'8"
MAXIMUM VISE OPENING ...................... 18.5"
WHEEEL DIAMETER ........................... 19"
TABLE WORKING SURFACE (L-R X F-B) ......... 30" X 33"
MAX WEIGHT CAPACITY ....................... 8,000 LBS.
MAX STROKE, 1 INDEX ....................... 24"
MAXIMUM PROGRAMMABLE LENGTH ............... 999.999"
APPROXIMATE MACHINE WEIGHT ................ 5,500 LBS.
- PCII MICRO-PROCESSOR CONTROL FOR LENGTH OF CUT
THE PCII'S MEMORY CAN HOLD AS MANY AS 99 INDIVIDUAL JOBS,
AND AS MANY AS 99 INDIVIDUAL STEPS
- HYDRAULICALLY ACTUATED SHUTTLE FEED WITH DUAL
- PROGRAMMABLE, HYDRAULIC POWER TILT FOR MITER CUTTING
- SINGLE CUT OR COMPLETELY AUTOMATIC CYCLE MODE OF OPERATION
- (2) SECTIONS OF 15' LIVE ROLLER CONVEYOR TABLE
- SELF-CONTAINED HYDRAULIC PUMP AND TANK
- 7.5 HORSE POWER BLADE DRIVE MOTOR AND ELECTRICAL CONTROLS
