Ameritec AM2S-SS7 squirt digital call generator
Ameritec AM2S-SS7 Squirt Digital Call Generator
Ameritec AM2 Squirt 1.5MBSS7 Digital Bulk Call Generator
* AM2S-S7/S7e SS7 Call Generators provide physical interfaces for one to four 1.544 Mbps T1 CCS trunks or 2.048 Mbps E1 CCS trunks and supports up to eight SS7 signaling links
The AM2 Squirt is an expandable call generator. The AM2 Squirt allows the user the ability to develop a test environment with low or high line counts, incremental expansion and multiple interfaces. Used alone it can simulate one to hundreds of telephony subscribers, and when grouped in a system, consisting of any Ameritec Squirt, Niagara or Crescendo , thousands of telephony subscribers can be simulated. Ideally suited to allow the user to develop a test environment with the ability to test highly complex call scenarios, under the control of the included FeatureCall GUI, a Windows based graphical user interface. The Squirt family has the flexibility to suit development, production, quality assurance or regression test needs.
The Ameritec AM2 Squirt has the ability to simulate telephony subscribers nd lots of them. Test configurations can be developed by chaining up to fifteen units together and controlling them via a single RS232 port, or up to 32 units can be controlled via an Ethernet LAN. Through the use of user defined call scripts and line protocols, users can tailor test scenarios to meet a broad range of testing requirements.
The actions of each simulated subscriber are independently controlled through unique parameter fields defined in user programmed Call Scripts. Call Scripts include capabilities for testing signaling, dialing, digit decoding, tone sending, tone receiving and path verification. The Scripts define calling patterns and can simulate practically any action a live caller can perform. Scripts can also simulate multiple subscribers allowing testing of multiple-party calls such as conference calling. The Ameritec FeatureCall GUI, is a Windows based Graphical User Interface that allows the user to create test systems. The user is now able to create a battery of tests, create traffic profiles, load test cases, view test results and create reports.
With the addition of the Ameritec Scriptmate the user is able to develop sophisticated test scripts by simply drawing the test sequence. Call Scripts are easily developed by dragging, dropping and interconnecting icons to create a graphical Call Flow Diagram. This Call Flow Diagram can easily be loaded into the Squirt unit using FeatureCall.
Applications that previously were too costly to test automatically can now be easily automated with the AM2 Squirt.
Central Office or PBX Switches and Network
Intelligent Network (IN) Applications
Computer Telephony Integration (CTI) systems and applications
Automatic Call Distribution (ACD) systems
Interactive Voice Response (IVR) systems
