Saint-gobain astipure AMC1310 pulsation damper-pfa/ptfe


Saint-Gobain AstiPure AMC1310 Pulsation Damper-PFA/PTFE
This is a Used Saint-Gobain AstiPure AMC1 310 Pulsation Damper. It was pulled from a decommissioned unit that was never put into production. The principle function of a pulsation damper is to damp out the pulse generated on the delivery stroke by pneumatically operated bellow and diaphragm pumps. Cosmetically, the unit is in good condition with some minor nicks and dirt from removal process. This unit only contains one port. The photos show the actual unit for sale. Only what is shown in the photos is included.
* Entirely made of High Purity PFA and PTFE
* No metal parts (internal or external)
* No rotating shaft or glands to cause leakage
* Operating temperatures 32 F (0 C) to +212 F (100 C)
* Pneumatically operated (dry air)
* Same spare parts as for the pump
* Max Air Connections: 2.5x4
* Fluid Connection: 10x13 or 3/8 x1/2
* Transfer of ultrapure acids
* Recirculation with filtration
* Circulation with control of the flow rates
* Pharmaceutical production line
