> Helwig T57 motor brushes 5/8 x 1-1/4 x 2-1/8" 4" leads
Helwig T57 motor brushes 5/8 x 1-1/4 x 2-1/8" 4" leads
We received these larger motor brushes in unused "as new" condition from
a source of water utility inventory stores spares. They are believed to fit larger GE
motors as used on elevators. In addition, they are a highly adaptable source of
electrographite for experimental uses such as electrochemistry or wherever
a conducting and low friction metallic free surface is needed.
Largest overall height is 2.13 inches. Width is 1.24 inches. Thickness is
0.62 inches. Four shunting leads are nearly 4 inches long and terminate
in a common angled spade lug intended for a 0.25 inch screw terminal.
Bottom angle is approximately 20 degrees. Top angle is approximately
30 degrees. An insulated block at top accepts a pressure spring.
Markings include HELWIG T57 6-89. The T57 material is believed to
be an electrographite in the 100 amps per square inch class.
Brushes have a split down the middle giving the effect of having two
You can click here to reach the Helwig website.
Please verify brush compatibility with your motor manufacturer or
directly with Helwig before ordering. This is believed to be a very
common and in-demand mainstream item. Normal price of this item new
is over $31, so those offered here are an outstanding bargain.
Received by us in utility stores poly bags. Apparently unused in "as new"
condition. Guaranteed usable in aps needing this size brush and material grade.
$5.85. AZ residents add 8.1% sales tax.
