Leviton surge suppressor panel 347/600V 3øy 57277-M3S
Leviton Surge Suppressor Panel 347/600V 3 Y 57277-M3S
Leviton 57277-M3S surge protective panel. Industrial Specification Grade, 7 mode, 4-wire & ground, 347/600VAC 3-phase WYE. It has the following features:
* Mounts at main distribution panels
* Hybrid suppression circuitry with built-in redundancy provides complete protection on all phases even if one module fails
* Modular design allows easy replacement of modules with the use of tools and without the need to shut down AC system power
* Provide normal (phase to neutral) and common mode (neutral to ground) protection for WYE-configured 3-phase AC systems
* Dry contacts for remote monitoring
* "Series Connection" parallel operated (Kelvin/feed-through) rated for 100 Amps maximum continuous line current using #3 AWG conductors
* Optically coupled remote-monitoring port allows use of the optional Remote Supervisor (Cat. #52000-RS).
* Dual-stage fuse protection for primary and secondary surge suppression circuits
* Housed in NEMA 12 case with hinged cover - surface or flush mountable.
