12" w 24" l gallmeyer & livingston 370 grand rapids sur
12" W 24" L Gallmeyer & Livingston 370 GRAND RAPIDS SUR
12" Width 24" Length Gallmeyer & Livingston 370 GRAND RAPIDS SURFACE GRINDER, AUTO IDF, 3X AUTO FE
12" X 24" GALLMEYER & LIVINGSTON "GRAND RAPIDS"
PRECISION HYDRAULIC SURFACE GRINDER
W/AUTOMATIC INCREMENTAL DOWNFEED
MODEL: 370 S/N: 370308 NEW: 1975
HYDRAULIC TABLE TRAVEL, LONGITUDINAL ............ 29-1/2"
HYDRAULIC TABLE TRAVEL, CROSS .................... 13-1/4"
WORKING SURFACE OF TABLE ....................... 12" X 24"
WHEEL SIZE ................................. 12" X 1" X 5"
GRINDING WHEEL SPEEDS (2) ................ 2000 & 2400 RPM
LONGITUDINAL TABLE SPEEDS .................. 3" - 150" IPM
AUTO CROSS FEED TO TABLE PER STROKE ........ 0.01" TO 1/2"
CONTINUOUS CROSS SPEED .......................... 120" IPM
AUTO INCREMENTAL DOWNFEED INCREMENTS .... 0.001" TO .0001"
MAX. TOTAL DOWNFEED FEED AMOUNT ................... 0.050"
VERTICAL MOVEMENT OF WHEELHEAD ....................... 16"
MAXIMUM DISTANCE FROM WHEEL TO TABLE (12" WHEEL) ..... 15"
APPROXIMATE FLOOR SPACE ..................... 109"W X 73"D
APPROXIMATE WEIGHT ............................. 5,700 LBS
AUTOMATIC "INCREMATIC" INCREMENTAL DOWNFEED
AUTO WHEEL RETRACTION @ COMPLETION OF GRIND CYCLE
HYDRAULIC LONGITUDINAL AND CROSS FEEDS
POWER "OVER-THE-WHEEL" WHEEL DRESSING W/AUTOMATIC
12" X 24" "ELECTRO-MATIC" FINE-DIVISION LONGITUDINAL
BAR POLE ELECTRO-MAGNETIC CHUCK
"ELECTRO-MATIC "NEUTROFIER II" VARIABLE HOLD NEUTROFIER
CONTROL, 300 WATT POWER SUPPLY (MODEL CEV3-6)
COOLANT SYSTEM W/TANK/PUMP/SPLASH GUARDS
HYDRAULIC OVER-THE-WHEEL DRESSER W/AUTO WHEEL COMPENSATION
SELF-CONTAINED HYDRAULIC SYSTEM MOTOR
3 HP 3/60/230-460 VOLT SPINDLE DRIVE
