Nortrac epa iv tractor ag tires frt end ldr & box blade
NorTrac EPA IV Tractor Ag Tires Frt End Ldr & Box Blade
The ideal tractor to have for around the home, at work or on the farm! Use for plowing and hauling big loads along with other agricultural and industrial activities. FREE power steering is included. 540 and 1000 RPM PTO. 2 stage clutch with live PTO. Three cylinder liquid-cooled diesel. 4-wheel drive works great for pulling out of mud and snow. Control panel includes fuel gauge, oil pressure gauge, hour meter and Amp meter. 3-pt. Category 1 hitch. Min. Operating Weight (lbs. (kg)): 2,734 (1,240), Wheel Base (in. (mm)): 64.9 (1,650), Wheel Tread Width - Front (in. (mm)): 41.3 (1,050), Wheel Tread Width - Rear (in. (mm)): 41.3 (1,050), Front Axle Ground Clearance (in. (mm)): 11.6 (295), Tires - Front: 6.00-12 (turf 26 x 7.5-12), Tire Inflation - Front (PSI): 26 to 29, Tires - Rear: 8.3-24 (turf 11.3-20), Tire Inflation in Field - Rear (PSI): 15.5 to 17.5, Tire Inflation in Transportation - Rear (PSI): 17.5 to 20, Turning Radius (in.): 104, Rated Traction Force (lbs.): 6,500N/1,433, Nominal Speed - Forward 1st (MPH (KM/H)): 1.0 (1.62), Nominal Speed - Forward 2nd (MPH (KM/H)): 2.0 (3.21), Nominal Speed - Forward 3rd (MPH (KM/H)): 3.3 (5.35), Nominal Speed - Forward 4th (MPH (KM/H)): 4.7 (7.51), Nominal Speed - Forward 5th (MPH (KM/H)): 9.2 (14.83), Nominal Speed - Forward 6th (MPH (KM/H)): 15.4 (24.75), Nominal Speed - Reverse 1st (MPH (KM/H)): 0.8 (1.29), Nominal Speed - Reverse 2nd (MPH (KM/H)): 3.7 (5.96), PTO Speed (RPM): 540/1,000, PTO Power (HP): 19, 3-Pt. Hitch Type: Category 1, Clutch: 2-Stage, Lift Capacity (lbs.): 808, Power Steering Pump Pressure (PSI): 2,810, Power Steering Pump Volume (GPM): 8.62, Engine Type: Three cylinder, vertical, water-cooled, 4-stroke, Engine Displacement (CI): 82.8, Rated Power (HP): 20, Rated RPM: 2,300, Fuel Capacity (gal.): 5.55, Engine Oil (gal. (qt.)): .92 (3.68), Front Drive Axle (gal. (qt.)): 1.19 (4.76), Transmission (gal. (qt.)): 3.7 (14.8), Hydraulics/Category 1 Hitch (gal. (qt.)): 2.38 (9.52), Radiator (gal. (qt.)): 2.64 (10.56) Standard 4ft. material bucket Lift capacity to full height at 2600 PSI: 930 lb. Maximum lift height (ground to lower bucket pin): 78 1/2in. Clearance with bucket dumped: 64in. Reach at maximum height (front of tractor to front of bucket): 32 1/2in. Maximum dump angle: 45 Bucket rollback: 22 * Digging depth: 3 1/2in. Overall height in carry position: 4ft. 9in. Hydraulic control valve requirements: two spool selective control valve required for loader and hydraulic controlled bucket cylinders Lift and bucket cylinders: double acting Bucket control: hydraulic twin cylinders Bucket cylinder size: 1 3/4in. bore x 17 1/4in. stroke Lift cylinder size: 1 1/2in. bore x 17 1/4in. stroke *NEVER ATTEMPT FULL ROLLBACK IN RAISED POSITION WITH FULL BUCKET.
