Nib bci mini-torr plus p pulse SPO2 monitor printer
BCI MINI-TORR Plus NIBP Pulse W/Printer
Listing Includes Adult Blood Pressure Cuff
Listing Does Not Include SpO2 Probe or Thermometer
The MINI-TORR PLUS NON-INVASIVE BLOOD PRESSURE MONITOR
provides a high quality reliable platform for your NIBP monitoring needs.
Its combination of reliability and flexibility makes the Mini-Torr Plus
a economical starting point for your long-range NIBP monitoring needs.
Pulse Rate 3-digit LED display, 0.30 inches (7.62 mm) high
Pulse Strength Logarithmically scaled 10-segment
Systolic & Diastolic Pressures
Temperature 3-digit LED display, 0.40 inches (10.16 mm) high
Determination 30 to 50 seconds typical
Time (max. 120 seconds in adult mode, 90 seconds in neonate mode)
Interval Times 1, 2, 2.5, 5, 10, 15, 20, 30, 45, 60, 90 mins
Calibration Factory calibrated
Inflation Pressure Adult: 50 to 300 mmHg
Default Inflation Adult: 175 mmHg
Adult High: 15 to 285 mmHg & OFF
Neonate High: 15 to 135 mmHg & OFF , Low: 10 to 130 mmHg & OFF
Adult Systolic: High - 200 mmHg , Low - 90 mmHg
Diastolic: High - 105 mmHg , Low - 40 mmHg
Mean Arterial: High - 140 mmHg , Low - 50 mmHg
Range 30 to 180 bpm (NIBP) (adult)
40 to 180 bpm (NIBP) (neonate)
Accuracy 2% or 2 bpm (whichever is greater)
Adult & Neonate High: 30 to 250 bpm & OFF (1bpm steps) , Low: 30 to 250 bpm & OFF (1bpm steps)
Alarm Default Adult: High: 150 bpm , Low: 45 bpm
Neonate: High: 150 bpm , Low: 50 bpm
Range 0 to 100 SpO2 (functional)
Accuracy 2 counts at 70 to 100%
Pulse Tone Volume adjustable or OFF
Range 84 F to 108 F (28.9 C to 42.2 C)
Accuracy 2 F, ASTM E1112-86 ( 0.1 C)
Base Unit 3.24 H x 8.5 W x 5.5 D
With Temp 3.24 H x 10 W x 5.5 D
Base Unit 3.5 pounds (1.6 kg)
With Temperature 4.2 pounds (1.9 kg)
Fully charged continuous-life 6 hours approximate, charge time 4 hours
Integrated Printer (Optional):
Text only, no graphics. Patient data log or trend tables.
510(k): K983796, K984618, K970801
