Pc_usb digital oscilloscope 200MHZ dso-5200A vista++++
PC system requirements: 32 Bit system (Windows98,Windows Me, Windows NT, Windows 2000, Windows XP ,VISTA )
1. DSO5200A Pc Softscope is based on the portable digital storage oscilloscope. High-performance Dso5200 has the following features: 200Mhz: analog bandwidth, 250MSa/S: real-time sampling.
2. Is a control Dso5200A of windows software. Easy to use
Dso5200A Softscope easy-to-use, it is intuitive and easy to understand. Big screen
Dso5200A Softscope use 720 * 480 screen size. Multiple data formats
Dso5200A Softscope can waveform storage with the following format: DAT file, JIP / BMP graphics files, Eexcel / word document.
DSO5200A Softscope with 23 kinds of measurements.
3 Dso5200A Virtual PC USB-based digital storage oscilloscopes
DSO5200A change before and after contrast brightness button:
DSO5200A oscilloscope afterglow effect can be seen the digital storage oscilloscope simulation results, so that you can more clearly see the line frequency signal
DSO5200A USB Softscope virtual oscilloscope functions of the Import and Export
DSO5200A points and data-line button allows you to a more intuitive waveform analysis
DSO5200A Softscope cursor measurements with a variety of ways
DSO5200A Softscope waveform with a variety of preservation:
DSO5200A Softscope bandwidth restrictions, so that you observe the low-frequency signal,
DSO5200A Softscope FFT spectrum analysis features that make you more that can be observed in a variety of frequency signal,
DSO5200A Softscope sentinel waveform observation time, the more easily you Analysis
DSO5200A Softscope some measuring more than 20 kinds of ways, too, is very effective,
DSO5200A Softscope horizontal position and the trigger point choice
DSO5200A Softscop high-low settings need input waveform
DSO5200A Softscope set sampling point average, thus the more realistic waveforms
If you DSO5200 Softscope not like the color of the horizon, you can
DSO5200A Softscope labelling on the screen: background and figures or other colors can be changed,
DSO5200A Softscope on the panel:
2. Softscope installation Important! In the use of DSO5200A Softscope software to be installed.
In Dso5200A must be installed before use Softscope software. This step should be in the first connection has been completed
2. Connects to the USB front-line B the USB port.
3. DSO5200A will be automatically detected.
4. DSO5200A document DSOXXXX.SYS drive will be set at a CD ROM Drives in the root directory.
5. DSO5200A drive will be used for the first time documents were found two drivers1 and driver2, with a corresponding DSOXXXX1.SYS and DSOXXXX2.SYS (drive Drivers below)
3 probe calibration. Dso5200A probe calibration.
1. When DSO5200 in the production, the probe was manual calibration order to obtain the best performance.
Voltage / time base, you can use Softscope, and the right panel operation
Then interface waveform is displayed:
You can also measured through the cursor test answers
.Click "DSO5200A.vi"( Pay attention to
your computer has been installed Labview)
2.200Mhz probe X 2 PCS: (1:1, 1:10)
3.DSO-5200A USB Software package
