New jet 14" x 40" large spindle bore lathe 321910
JET GH-1440ZX, 14" X 40" 7-1/2 HP 3-Phase ZX Series Large Spindle Bore Lathe
* ISO 9001 certified manufacturer
* Chrome molybdenum headstock gears are hardened, ground, and shaved
* Universal gearbox allows inch, metric, diametral, and module pitch threads, no change gears required
* Carriage features one-shot lubrication and Turcite B on bed sliding surfaces
* One-piece cast iron base absorbs vibration allowing heavier cuts
* High quality ANSI class 50 wear-resistant cast iron bed ways are hardened and ground
Motor 7-1/2 HP, 230/460V Pre-wired 230V 3 Ph Spindle Bore 3-1/8" Spindle Mount D1-8 Number Of Spindle Speeds 12 Range Of Spindle Speeds 42 - 1,800 RPM Range Of Inch Threads 1-5/8 - 72 Number Of Inch Threads 61 Range Of Metric Threads .05 - 20 mm Number Of Metric Threads 24 Distance Between Centers 40" Width Of Bed 13-3/8" Swing Over Bed 14" Length Of Gap 12-1/4" Swing Through Gap 23-5/8" Compound Slide Travel 5-1/8" Cross Slide Travel 9" Swing Over Cross Slide 7-5/8" Range Of Longitudinal Feeds .0015 - .0913 in./rev. Range Of Cross Feeds .0006 - .0365 in./rev. Number Of Longitudinal & Cross Feeds 122 Spindle Taper W/ Sleeve MT-7 (MT-5) Maximum Tool Size 1" x 1" Carriage Travel 35" Taper In Tailstock Spindle MT-4 Tailstock Spindle Travel 5" Steady Rest Capacity 3/8" - 7" Follow Rest Capacity 1/2" - 3-1/2" Overall Dimensions W/ Stand 97-1/2" x 40" x 46-7/8" (L x W x H)
* 14" x 40" 7-1/2 HP 3-Phase ZX Series Large Spindle Bore Lathe - 321910
* 10" 3-Jaw Chuck w/ Top Reversing Jaws
* Full Length Splash Guard & Coolant Return
* Large Easy-to-Use Foot Brake
* Centrally Located Controls w/ Jog Button
* Tool Box & Adjusting Tools
