Lincoln invertec V205-t K2350-2 tig welder one pak
Lincoln Invertec V205-T AC/DC TIG Welder One-Pak Package K2350-2
Unit Includes- Invertec V205-T AC/DC (K1855-4)
- TIG-Mate 17 TIG Torch Starter Kit (K2266-1)
- Added Stick Crisp Mode for exceptional Fleetweld 5P and 5P+ (E6010) Performance.
- Improved TIG starting. Now starts DC(-) to maintain a sharp tungsten.
- Adjustable DC strike mode Allows adjustment of a hotter or colder start depending on the tungsten diameter.
- AC/DC inverter for TIG with advanced inverter technology to optimize arc performance.
- Adjustable AC output frequency allows the operator to focus the arc minimizing the heat affected zone.
- Extended AC Balance Control helps maintain a pointed tungsten to direct the arc in the weld joint.
- Selectable waveshapes Square wave for fast travel speeds and excellent puddle control, sine wave for a traditional softer sounding arc, triangular wave to reduce the heat input into the weld at low amperages.
- High quality stick welding with such popular Lincoln electrodes as Fleetweld 5P, 35, 37, 180 and Excalibur 7018.
- Voltage Reduction Device (VRD). When enabled from the set up menu reduces the open circuit voltage in STICK mode for use in electrically hazardous conditions or when the use of a VRD is required.
- 200 amps @ 40% duty cycle is the highest output rating in this machine class.
- Auto-reconnects for single phase 115/230V 50/60 Hz input allows the flexibility to weld in the shop or take in the field where 230V may not be available.
- Weighs in at a mere 38 lbs. (17.3 kg) making it easy to carry around the shop or job site.
- Easy to read sequence diagram with LEDs displays selected parameter for easy setting with a single knob.
- Fan-As-Needed (F.A.N.) fan only operates when needed to reduce power consumption, noise and dust in machine.
- Newly designed using the latest power electronic technology for improved reliability.
- Three-Year Lincoln Warranty on parts and labor
You can see the full spec sheet here.
