New rgb led color light sensor module detection TCS230
40.64(L) X30.48 (W) X29.00(H) 0.20mm
This self-made color sensor module is a complete RGB color sensor module for color detection and sorting operations. By integrating a TCS230-the programmable color light-to-frequency converter by TAOS and a powerful microcontroller 16F690, it has made itself different from other sensor modules that output merely pulse.In addition to the ability to output analog voltage,both UART and SPI interfaces make system integration and further development easier and more convenient. Moreover, the calibration function can help output more accurate data.
* Analog: RGB voltage signal linear output
* Digital: UART half duplex, SPI slave mode
* DIP-like packaging, which facilitates system integration
* Storage temperature:-20 C to 85 C
* Storage humidity range: 0 to 90 % RH
* Temperature operating range:-15 C to 60 C
* Humidity operating range: 0 to 85% RH
* Supply voltage: DC 3.3V to 5V
Digital Interface Characteristics:
* Portable color identification system
* Color monitor to color printing
* Process control to printed materials
* Other occasions requiring color detection and sorting operations
* TCS230 Color Sensor Module 1
Go to Download Center for driver, manual or application
