16.5" w 16.5" h kasto kasto twin L4 horizontal band saw
16.5" W 16.5" H Kasto KASTO TWIN L4 HORIZONTAL BAND SAW
16.5" Width 16.5" Height Kasto KASTO TWIN L4 HORIZONTAL BAND SAW, Fully Automatic PLC Cntrl,Double C
KASTO AUTOMATIC HORIZONTAL BANDSAW
MODEL: KASTO TWIN L4, YEAR: 2001
CUTTING RANGE ROUND 90 DEG ... 420mm ........ 16 1/4"
CUTTING RANGE FLAT (W x H) ... 420 x 420mm .. 16 1/4"x 16 1/4"
FEED LENGTH, SINGLE INDEX .... 1500mm ....... 59 1/2"
MULTIPLE FEED ................ 20,000mm ..... 787 1/2"
SMALLEST CUT OFF LENGTH ...... 6mm .......... 1/4"
SMALLEST CUTTING DIMENSION ... 10mm ......... 1/2"
PIECE IN SINGLE CUT ........ 15mm ......... 2/3"
PIECE IN AUTO OPERATION .... 80mm ......... 3"
SAW MOTOR FREQUENCY CONTROL .. 4kW .......... 5HP
TOTAL POWER .................. 6.5kW ........ 8HP
CUTTING SPEED (INF VAR) ...... 20-110m/min .. 66-363ft/min
DIMENSIONS OF SAW BLADE ...... 5090 x 41 x 1.3MM
MATERIAL SUPPORT HEIGHT ...... 700mm ........ 27 1/2"
TOTAL DIMENSIONS ............. 2415 x 2240mm. 95" x 88"
HEIGHT (SAW HEAD DOWN) ....... 1725mm ....... 68"
HEIGHT (SAW HEAD UP) ......... 1915mm ....... 75 1/4"
TOTAL WEIGHT ................. 2200kg ....... 4840 lbs
W/ 1500mm(59") FEED LENGTH . 2415 x 3000mm. 95" x 118"
COMPACTCONTROL (SIEMENS S5 COMPATIBLE) WITH AN EASY
TO SWIVEL OPERATOR'S PANEL ENSURES OPTIMUM MACHINE OPERATION VIA FUNCTION KEYES. FOR MASS PRODUCTION, UP TO 30 DATA
RECORDS CAN BE PRE-SELECTED VIA PUSH BUTTON. AFTER MAKING
THE DESIRED NUMBER OF CUTS, THE MACHINE SHUTS OFF
AUTOMATICALLY. BY REDUCING SET-UP TIMES TO A MINIMUM,
MAXIMUM CUTTING PERFORMANCES ARE ACHIEVED IN AUTOMATIC MODE.
THE PRECISE DRIVE VIA BALL SCREW SPINDLE IN MATERIAL FEED
GUARANTEES AN EXACT MATERIAL LENGTH POSITIONING
FEED CONTROL WITH KASTO-UNIVERSAL HYDRAULIC UH
THIS MEANS CONSTANT FEED RATE WHEN CUTTING SOLIDS RESP
CONSTANT CUTTING FORCE WHEN CUTTING PROFILES AND TUBES.
PRE-SELECTED ADJUSTMENT ON OPERATORS PANEL. THE KASTO-
UNIVERSAL HYDRAULIC SYSTEM GUARANTEES AND OPTIMUM ADAPTATION
TO SAW FEED ON EACH DIAMETER TO BE CUT AS WELL AS AN
AUTOMATIC OVERLOAD SAFETY OF THE SAW BAND. THE SAW BAND FEED
RATE CAN BE PRE-SELECTED INFINITELY VARIABLE AND CONTROLLED
AND OPTIMIZED VIA CUTTING PRESSURE MANOMETER.
THIS INNOVATIVE FEED SYSTEM GUARANTEES SHORT CUTTING TIMES
AND HIGH IDLE TIMES AS WELL AS PRECISE CUT-OFFS
- HORIZONTAL VISE, CLAMPING ON BOTH SIDES OF THE SAW BAND
- THE MACHINE HEAD IS GUIDED ALONG TWO VERTICAL COLUMNS.
CONDITION: SUPERB - VERY LOW HOURS
