Ryobi 3302 + crestlines + tempest dryer + plate punch
* CRESTLINE Dampening on BOTH Heads
* Tempest Air Drying System
* Diagonal Micro-Adjustment of the Paper Feed Drum
* 13" x 18" A3 Size Portrait Format
* Condition: This press is in good condition. It has been print tested and is working very well. It is sure to be a great addition to your shop!
* High-quality multi color printing is necessary to remain competitive in today's printing market.-
* Ryobi has developed the innovative Ryobi 3302M, an offset press which handles paper sizes up to 13"x 18" A3. It is equipped with a 16 roller inking system including 3 form rollers to guarantee beautiful reproduction of halftones and solid colors. The registration device and the true 2-color build make this press extremely well-suited for multi-color jobs. The inching feature greatly simplifies operation.-
* In every respect of features and operational ability, this press is at the top of its class. The Ryobi 3302 is the press of choice for high quality and economical multi-color offset printing.
* One Touch universal feeder provides dependable paper feeding
* 21" large capacity delivery pile
* Crestline Dampening System.
* Super Blue Anti Tracking System.
* Powerful, inverter controlled motor.
* Low maintenance and sturdy construction.
* Safety features for operator and press.
* Heavy duty inking system for beautiful halftones and solid printing.
* Straight edge clamp with plate positioning pins.
* Double spring grippers ideal for printing large solids.
* Registration device for multi-color printing.
* Dial type image position adjustment
* Original diagonal image micro-adjustment device
* Feeder pre-pile system for efficient long runs
* Simple ink roller cleaning and centralized lubrication
* Maximum: 13.39 x 17.72"
* Maximum Image Area: 13 x 17.24"
* Plate Size: 13.19" x 19.09"
* Paper Thickness: 0.0016" - 0.012"
* Printing Speed: 3,000 - 10,000 SPH
* Plate Clamp Type: Straight edge clamp with plate positioning pins
* Over Blanket Size: 13.54" x 19.53" x 0.075"
* Under Blanket Size: 13" x 18.11" x 0.024"
* Feeder and Delivery Systems:
* Universal Feeder System
* Diagonal Micro-Adjustment of the Paper Feed Drum
* Ink Rollers: 16 (3 form rollers)
* Dampening System: CRESTLINES on BOTH Heads
* Gripper Margin: 8mm / 0.315"
* Lubrication System: Centralized Lubrication
