National instrument scxi-1102B 32-ch amplifier module
National Instruments offers a variety of 32-channel analog input modules for SCXI, including the SCXI-1100, SCXI-1102 Series, and SCXI-1104 Series. It is still in perfect working condition, Like-New. Product Condition:Used
This card was recently pulled out from an engineering lab. It is still in perfect working condition, Like-New. National Instruments offers a variety of 32-channel analog input modules for SCXI, including the SCXI-1100, SCXI-1102 Series, and SCXI-1104 Series. The programmable gain and filter settings are ideal for conditioning a variety of millivolt, volt, and current inputs. Each module multiplexes the 32 channels into a single channel of the DAQ device, and you can add modules to increase channel count. Use SCXI Advisor to configure an SCXI data acquisition system based on this module.
* SCXI-1600 (USB) is recommended for controlling this module; also compatible with M Series
* Programmable gain settings
* NI-DAQmx Measurement Services software to simplify configuration and measurements
* 333 kS/s maximum sampling rate
* Operating System / Target Windows, Real-Time, Linux
* Measurement Type Current, Temperature, Thermocouple, Voltage
* Number of Channels 32 DI
* Simultaneous Sampling No
* Input Impedance 1 GOhm
* Maximum Voltage Range -10..10 V
* Minimum Voltage Range -100..100 mV
* Signal Conditioning 0-20 mA current input, Cold-junction compensation, Low-pass filtering, Open thermocouple
* Available Filters 200 Hz
* Number of Counter/Timers 0
* Triggering Analog, Digital
* Triggers cDAQ Chassis No
* National Instrument SCXI-1102B Amplifier Module
