Ctc model 43558 programmable multi-stage thermostat
Condition: New CTC Model 43558 Programmable Multi-Stage Thermostat
CTC Model 43558 Programmable Multi-Stage Thermostat
The Model 43558 digital multi-stage heat pump thermostat combines the latest in digital temperature control to ensure a trouble-free installation every time. The auto recovery and energy monitor features assure the homeowner maximum comfort and energy savings, evenin the coldest weather, while energy cost savings pay back their original investment.
* Latching relay assures system compatibility
* Energy Monitor - stores the amount of time the heating and AC system have been operating
* Temporary, Permanent, and Vacation Hold
* 7 Day Programming - 4 program periods per day
* Armchair programming - program your thermostat while sitting down, then snap it on the wallplate
* Programmable fan - allows fan mode to be set to continuous on or "auto" during each program period
* "Home Today" feature - quickly override your program if you happen to be home when you are normally away
* AC powered with 2 AAA battery backup (must have 24V Common, batteries for backup only)
* Optional hardwire remote sensor -with temperature averaging feature - supports up to 2 remote sensors
* 2-stage heat pumps with 2 heat / 2 cool
* 2-stage heat pumps with 2 heat / 1 cool
* Conventional two stage heat/cool systems
* Multi-stage heat/cool systems
* Not compatible with line voltage (110V / 220V) systems
* Current draws 0.1 to 1.5 amps per terminal. Max 2.5A total.
* Display temperature limits: 40 -95 F
* Operating differential +/- 1 F
* Compressor protection: 4 min. delay on break
* Terminations: R, Y1, Y2, W1, W2, E, O, B, G, L, C
* Remote Sensor Terminations: RS1+, RS1-, RS2+, RS2-
* Dimensions - 7" W X 4-3/4" H X 1-5/8" D
