> South bend vertical milling machine manual, parts
South bend vertical milling machine manual, parts
Vertical Milling Machine Parts Manual
This is a reproduction, not a photocopy, of an original South Bend Vertical Milling Machine Parts Manual, plus a sales catalog. This manual covers all of the components to this unusual and very well manufactured machine. It includes the gear system for a thirty speed table drive, the hydraulic system, and the cooling system. It contains all of the various motors and part numbers for metric. This manual comes with a sales catalog, which covers set up, accessories, and specifications like a lot of the old catalogs contained. This is a must have for anyone who owns this machine.
General Care.............................................................1,2
Knee.........................................................................3,4
Saddle.........................................................................5
Table...........................................................................6
OverArm..................................................................7,8
Head Showing Spindle............................................9-12
Head....................................................................13-16
Drive Housing.......................................................17-20
Motors.................................................................21-24
Feed Control & Selector Blocks............................25,26
Cylinder Block & Rack.........................................27,28
Hydraulic Pump & Reservoir.................................29,30
Table Power Feed................................................31,32
Table Drive Clutch................................................33,34
Table Feed Control...............................................35,36
Table Feed Gear Box............................................37,38
Gear Box Pedestal................................................39,40
Features.....................................................................41
Alternate Motors........................................................41
Controls.....................................................................42
Power Feeds..............................................................43
Specifications.............................................................44
