20MM 2-bolt flange bearings UCFL204-20MM (8 pieces)
This is high quality self aligning set-screw bearing with cast iron 2-bolt flange.
The bearing is commonly used for HVAC, Coveying, Processing, Feed Mill, Agricultural and MANY other industrial applications.
UCFL204-20MM = 20MM Set-Screw Insert Bearing & 2-Bolt Flange Housing
See below for dimensions of this 2-Bolt Flange Unit.
"e" (center of bolt hole to center of bolt hole) = 3-35/64" "a" (overall lenght) = 4-7/16" "s" (bolt hole) = 15/32"
"g" = 7/16" "i" = 19/32" "l" = 1" "b" = 2-3/8" "Z" = 1-5/16" "Bi" = 1.2205" "d" (shaft / bore) = 20MM
Need bigger quantity of bearings.. Ask us since we offer volume discount pricing.
