Rohde & schwarz vector analyzer zpv with 2GHZ E3 tuner
Rohde & Schwarz Vector Analyzer ZPV with 2GHz E3 Tuner
Cosmetically in good condition.
This is an open frame model, there is no case.
Comes with the original R&S E3 Tuner Manual
The item pictured is the item for sale.
Model ZPV is designed for critical applications in control engineering and for crystal, antenna, amplifier, and filter measurements. Three plug-in tuners and appropriate accessories optimize performance by frequency range and test methods. Measurements include amplitude and phase, y- and z- parameters, s- parameters, group delay, reflection coefficient, and impedance.
ZPV-E3 allows vector measurements, two-port and group-delay
measurements in 50 ohm coaxial systems over a wide frequency and amplitude range.
FREQUENCY0.3 - 2000 MHz, usable to 2.5 GHz
Channel A 1200 uV (typ 400 uV), <1 MHz
Range-180 degrees to +180 degrees
Accuracy (see Note)0.5 degrees
