> 2.5" spdl 39" x tos WH63 horizontal boring mill, #4MT,
2.5" spdl 39" x tos WH63 horizontal boring mill, #4MT,
2.5" Spdl 39" X Tos WH63 HORIZONTAL BORING MILL, #4MT,
2.5" Spindle 39" X Axis Tos WH63 HORIZONTAL BORING MILL, #4MT, Rotary Table, Tailstock, DRO,
2 TOS TABLE TYPE HORIZONTAL BORING MILL
MODEL: WH63, SN: 109-30, NEW 1980
SPINDLE DIAMETER ...................... 2-1/2"
SPINDLE TAPER ......................... #4MT
VERTICAL TRAVEL OF HEADSTOCK .......... 28
TABLE CROSS TRAVEL .................... 39
TABLE LONGITUDINAL TRAVEL ............. 39"
SPINDLE SPEED RANGE (21) .............. 18 TO 1800 RPM
ROTARY TABLE SIZE ..................... 35 x 31
MAXCIMUM WORKPIECE WEIGHT ............. 4,500 LBS.
FLOOR SPACE REQUIRED .................. 160"L x 85"W x 90H
APPROXIMATE WEIGHT .................... 17,000 LBS.
- ANILAM THREE AXIS DIGITAL READOUT
