> Matsuura ra-11 s-542-10,000
Matsuura ra-11 s-542-10,000
X-AXIS TRAVEL (LONGITUDINAL)...........23.62"
Y-AXIS TRAVEL (CROSS)..................16.14"
Z-AXIS TRAVEL (VERTICAL)...............18.5"
PALLET TOP TO SPINDLE END..............5.9" TO 24.4"
PALLET SIZE (2 PALLETS-SHUTTLE TYPE)...23.6" X 14.9"
SPINDLE SPEEDS - (2 SPEED GEARED)......30 TO 7,000 RPM
SPINDLE MOTOR..........................10 HP
SPINDLE TAPER..........................BT 40
CUTTING FEED RATE......................0.1 TO 196 IPM
RAPID TRAVERSE (X/Y/Z).................590/590/472 IPM
AUTOMATIC TOOL CHANGER.................20 POSITIONS
MACHINE SIZE..............146" W, 110" DEEP, 106" TALL
MACHINE WEIGHT............9,680 LBS
* RIGID TAPPING VERY WELL MAINTAINED
COMES WITH 12 ASSORTED TOOL HOLDERS
