15 hp arco wand central vacuum cleaning system; used
15 HP ARCO WAND CENTRAL VACUUM CLEANING SYSTEM; USED
ARCO WAND CENTRAL VACUUM CLEANER. MODEL PB-15-BPKG; 15 HP, SN 110306. MANUFACTURED BY AMERICAN VACUUM COMPANY. FILTER RECIEVER IS MANUAL SHAKER TYPE COLLECTOR, 36" DIA X 60" STRAIGHT SIDE X 88" OVERALL HEIGHT. THE FILTER RECEIVER COMES COMPLETE WITH A FILTER ACCESS DOOR, USING OVER 100 SQ FEET OF DUST FILTER SLEEVES. UNIT HAS MANUAL DISCHARGE BUTTERFLY VALVE ON BOTTOM OF CONE.MULTI-STAGE CENTRIFUGAL BLOWER PACKAGE MOUNTED IN AN ENCLOSURE COMPLETE WITH EXHAUST SILENCER. BLOWER IS 15 HP, 460 VOLT, 3 PHASE. BLOWER ENCLOSURE IS 24"W X 36"L X 45" H. UNIT HAS 3" VACUUM LINE. ORIGINALLY DESIGNED FOR 2 REMOTE START STOP STATIONS AND PIPING FOR AT LEAST 14 DROPS (PIPING AND DROPS NOT INCLUDED).THE UNIT IS CAPABLE OF 90 SCFM PER 1 1/2" HOSE AND CONVEYING VELOCITY OF 5000 FPM. A LARGE GAYLORD BOX OR A LARGE DRUM CAN BE PLACED UNDER THE FILTER RECEIVER. MAIN ELECTRICAL CONTROL PANEL IS MODEL 609-BAB-IR. SYSTEM MANUFACTURED IN 2006.
