Agilent hp 70004A 70100A 70904A
70004A Color Display AND MAINFRAME70100A Power Meter Modular, 50 GHz Max70904A System RF Section 2.9 GHz Max, Synthesized
PICTURE IS ONE OF THE MODULES ON SALEThe HP / Agilent 70004A display has a removable custom hardkey panel, a key to aid in selecting the MMS instrument to be controlled, and several advanced firmware features. Up to four modular instruments can be shown on the display simultaneously. The display keyboard (softkeys and hardkey panel) controls one instrument at a time. The INSTR key lets you pass control from one instrument to another with a single keystroke. The 70004A sends displayed graphics to a HP-IB printer or plotter. It also supports the HP PaintJet printer so you can have full color printed documentation of your test results. The HP-HIL connector on the front panel allows you to attach an Agilent 46021A or 98203C HP-HIL keyboard. This can be used to control the system front panel or to enter user titles or spectrum analyzer commands and small downloadable programs (DLPs).
The HP / Agilent 70100A Power Meter measures power in the range of -70 to 44 dBm over the frequency range of 100 kHz to 50 GHz using 8480 Series Power Sensors. A 100 mW 50 MHz power reference is provided at the front panel for calibrating the meter to the power sensor.
The HP / Agilent 70904A RF section converts the RF input signal to 21.4MHz and provides up to 70dB of input attenuation in 10dB increments. Either AC or DC coupling may be selected using the front panel controls.
