> Tektronix 2230 service & operators manuals ( 2 volumes)
Tektronix 2230 service & operators manuals ( 2 volumes)
for the Tektronix 2230 Oscilloscope in PDF format on CD-ROM.
Two, reproduction grade scans of the original commercial manuals (not a military TM manual).
Detailed information about each manual listed below.
THESE SCANS ARE BOOKMARKED IN DETAIL
TEXT SEARCHABLE FOR FASTER NAVIGATION
1. Tektronix 2230 OSCILLOSCOPE , Service
This volume covers Maintenance, Calibration, Theory of Operation, Block Diagrams, Board Component Locations, Schematics, Parts lists and Exploded Mechanical Views. P/N 070-4999-00, 450-pages in 22-MB PDF format file MB,
2. Tektronix 2230 OSCILLOSCOPE, Operators Detailed large format users guide with extensive function by function operation of this very versatile oscilloscope. P/N 070-4998-01, 121-pages in 5-MB pdf file.
