Generalaire GFX3 automatic digital humidistat E2
GENERAL GFX3 24V AUTOMATIC DIGITAL HUMIDISTAT
REPLACES GENERALAIRE E2, GENERALAIRE 7035
CONSTANT POWER MUST BE SUPPLIED TO UNIT - NOT RETURNABLE IF YOU FAIL TO HAVE CONSTANT POWER
SWITCHING LOAD 1 AMP MAX 30 VOLT
OUTDOOR SENSOR 18" CAN BE RUN TO MAX 200' (61 M) WITH STANDARD 18 GAUGE THERMOSTAT WIRE
ACCURACY -RH (77 F, 25 C) 10% - 90% RH 3% RH
ACCURACY DRIFT PER YEAR 0.5% RH
ACCURACY INDOOR TEMP 2 F , 1 C
ACCURACY OUTDOOR TEMP 2 F , 1 C
RESOLUTION, TEMP OR RH 1 OR 1%
In Automatic Mode the GFX3 humidistat will adjust the humidity in your home based on the outdoor temperature, lowering the humidity in cold weather to reduce condensation. The humidistat can operate in Manual Mode to control humidity to a specific relative humidity. In most homes Automatic Mode is preferred to reduce condensation on windows and within the structure. Manual Mode is necessary where the outdoor temperature sensor cannot be installed. Manual Mode may be desirable where valuable artwork, instruments, or woodwork demand constant humidity. The LCD screen is backlit and easy to read. Operation and Installation are simple. The GFX3 can be mounted on an interior wall or on the return duct of the HVAC system.
Outdoor Temperature Compensation Mode
10% - 75% Relative Humidity Control
