SPX2941U5 1A low dropout voltage regulators lot of 10
SPX2941U5 1A Low Dropout Voltage Regulators by Sipex Corporation
PRODUCT DESCRIPTION: The SPX2941 is a low power positive Adjustable Voltage Regulator. The SPX2941 offers 1A output current with dropout voltage of only 0.5 Volts with a maximum of 1V dropout over temperature. The quiescent current is 30mA at differential output of 5V and output current of 1A. The higher quiescent current exists only when the device is in dropout mode (VIN VOUT < 3V).
Other key features of this device include higher output current, positive transient protection up to 60V (Load dump), and ability to survive an unregulated input voltage transient of -20V below ground (reverse battery). The regulator will automatically shut down to protect both the internal circuits and the load. This device also features short circuit and thermal overload protection.
The SPX2941 is offered here in a 5-pin TO-220 package compatible with other adjustable regulators. This device offers an adjustable output voltage from 5V to 20V. SPX2941 is a direct replacement to LM2941.
* Internal Short Circuit Current Limit
* Dropout Voltage 0.5V at 1A Output
* Mirror Image Insertion Protection
* Unregulated DC Input Can Withstand -20V Reverse Battery and +60V Positive Transients
* Direct Replacement For LM2941 Socket
* Adjustable Output Between 5V to 20V
* TTL, CMOS Compatible ON/OFF Switch
* Portable / Palm Top / Notebook Computers
