(10)watt stopper control & power module hb-150-1 sensor
LOT of 10 (each: 20 total items)
The HB-150-1/2/3/4 occupancy sensors turn lighting on and off based on
occupancy. They are designed for warehouse and high bay applications.
The sensors use passive infrared (PIR) sensing technology that reacts to
changes in infrared energy (moving body heat) within the coverage area. Once
the space is vacant and the time delay elapses (adjustable from 30 seconds to
30 minutes), lights will turn off. Sensors must directly see motion of an
occupant to detect them, so careful consideration must be given to sensor
placement. Avoid placing the sensor where shelving or other obstructions may
block the sensor s line of sight.
The HB sensors are modular and are made up of two parts, a Power Module
(HB-150) and a Control Module (HB-1, HB-2, HB-3 or HB-4). The HB-150
operates with 120 or 277VAC single-phase, or 208 or 240VAC 2-phase.
The HB-150-1 Fresnel lens is designed to detect walking motion when mounted
at 40 above the floor. When mounted at 40 , in optimal conditions, the lens has
a 60 linear detection range. Ideal for Aisleways.
This listing is for both the Control Module HB-1 and Power Module HB-150
*These units are new but do not include box or instructions.
