Accutime accu time ats series 4000 time clock terminal
ACCUTIME ACCU TIME ATS SERIES 4000 TIME CLOCK TERMINAL
The Series 4000 can accommodate challenging business needs.
The Series 4000 terminal is designed for the most demanding time and data collection needs. Utilizing an advanced dual microprocessor technology, the base unit offers TCP/IP, RS232/RS485 or modem connectivity. Auxiliary ports are included for digital I/O devices, contact, and media scanners, making the Series 4000 ideal for alarm and access control. The 512K Byte Flash memory allows for easy, on-line program updating or modification without product disassembly - no extra tools or outdated modules to purchase. The Series 4000 terminal, housed in a die-cast metal enclosure, is well suited for high-traffic environments.
Display: 2 or 4 Line x 20 Character backlit super-twist LCD.
Indicators: Yellow LED Low Power indicator. Two programmable LEDs: Red and Green. Diagnostic LEDs for Ethernet communication.
Speaker: Dual tone audible annunciator.
Programming: 'C' programming language or third party custom application packages.
Interface: TCP/IP Ethernet 10-base-T (802.3). EIA Standard RS232 or RS485 (2 or 4 wire).
Internal 9600/19.2 Baud Modem operation. Serial Interface Printer port.
Power: +10 to +17 VDC (+12 VDC @ 250 milliamps Nominal). Local, remote or centrally powered. Non-interruptible power source w/charger
Certification: This device complies to the conformance of FCC Rules Part 15, Class A.
Self Test: ACCU-RATE on-board terminal set-up and full feature diagnostics.
Memory: 128K Byte of capacitor backed memory. Expandable to 768K Byte (2000+ employee base-program dependent). 192K Byte Flash memory.
Environment: Operation: 32 to 110 F (0 to 43 C).
Enclosure: Die cast aluminum housing with steel, key-lockable base assembly.
Keypad: Software defined function keys. Large 20 key tactile 4x5 matrix. Custom user defined keypad legends.
This clock has been tested and works great. It does not come with a power supply. It uses a DC 12V 1000ma power adapter.
