> Watkiss vario slimvac + bookletmaster pro - vacuum feed
Watkiss vario slimvac + bookletmaster pro - vacuum feed
* 7-Bin Air Feed Collator
* Touch-Pad LED Display / Screen
* Serial Number: WA/VAR/2879
* Watkiss Vario Bookletmaster Pro
* Serial Number: WA/BMP/1052
* Watkiss Vario Trimmaster Pro
* Serial Number: WA/TMP/1048
* Condition: This system was bought new used sparingly. The unit is in excellent condition throughout. The Bookletmaker tucks in underneath the collating tower as a tremendous space-saving feature of the Watkiss VARIO line of bookletmaking equipment. What a wonderful system this will make for the lucky winner!
* Efficient, reliable and productive.
* Built-in bad set diverter ensures constant running.
* Load and unload the machine from a single position:
* This means less operator fatigue, less downtime and higher productivity.
* A single user-friendly control panel runs the whole system:
* Easier to operate and quicker to start-up.
* Saving space means saving money.
* Robust high quality manufacture and award winning design.
* Field upgradeable by adding extra feed bins.
* Watkiss SlimVAC Collating Tower:
* Configuration: up to 16 bins per tower
* Production: up to 5,000 feeds per hour
* Sheet sizes: 4.7" x 6.3" to 14.3" x 20.5"
* Stock range: 40 to 240 gsm
* Detection: Electronic detection for miss, double, jam and empty bin
* Sound emission: typical 75dB (A) for machine in use
* Watkiss Vario Bookletmaster Pro:
* Designed for maximum performance and cost effectiveness, the Bookmasters may be used off-line for hand feeding, or on-line to Watkiss Vario and Watkiss DigiVAC collators, as well as other manufacturers' bench-top and table-top collators. Intelligent bi-directional communication ensures collator and booklet maker both stop should any type of error occur. The sheets are jogged at the end and on each side, both above and below the fold rollers, to ensure perfectly squared up sheets every time.
* They are then stapled with the unique BookMaster stapling system before being passed through steel fold rollers and an additional pair of crushing rollers to produce a neat crisp fold. Finished booklets are delivered onto a high capacity conveyor at an ergonomically comfortable height.
* The BookMaster has a unique low impact stapling mechanism that ensures virtually maintenance free operation. The main wearing parts are included in the staple cartridge (rather than the staple head), and so they are replaced every 5,000 cycles when the cartridge is changed. In effect, changing the cartridge also services the staple head. As a result, over one million cycles can be run before maintenance is required. A sensor alerts the operator when the staple cartridge is nearly empty, and replacement takes only a matter of seconds.
* A fully automatic version, the BookMaster Pro, has simple push button operation to adjust the sidelays, end jog and stitch/fold/trim position. When used on-line with a Watkiss Vario or DigiVAC+ collator, a single integrated control panel runs the entire system. When used off-line, or with other makes of collator, a separate control panel is available. Three memories automatically set-up for standard sheet sizes (A3, A4 and A5) whilst 6 other memories can store custom settings.
* Production: Up to 2500 per hour
* Min/Max input size: 8.25" x 5.5" to 19" x 12.6"
* Min/Max booklet size: 4.13 x 5.5" to 12.6" x 9.5"
* Max booklet thickness: 22 sheets (of 80gsm)
* Min/Max stitch pitch: 4.5" or 5.4"
* Watkiss Vario Trimmaster Pro:
* Sound emission: 74dB (A) (stitch, fold & trim)
