19.8" x 40" kellenberger 1000U univ id/od grinder
19.8" x 40" KELLENBERGER 1000U UNIV ID/OD GRINDER
19.8" x 40" KELLENBERGER "SWISS" SUPER-PRECISION
UNIVERSAL I.D./O.D. CYLINDRICAL GRINDER
** MACHINE IS CURRENTLY SET-UP WITH 4" FACTORY RISERS
** MACHINE CAN BE EQUIPPED TO GRIND O.D., I.D & FACE
MODEL: 1000U S/N: 2220/460 MFG. 1982
DISTANCE BETWEEN CENTERS ...................... 39- 3/8"
DISTANCE BETWEEN CENTERS W/TAILSTOCK
OVERHANGING .................................. 47- 1/4"
HEIGHT OF CENTERS, WITH REMOVABLE RISERS ..... 9- 27/32"
MAXIMUM SWING WITH FACTORY RISER BLOCKS .......... 19.8"
LONGITUDINAL TABLE TRAVEL ................... 51- 13/16"
LONGITUDINAL TABLE TRAVEL PER TURN OF HANDWHEEL:
COARSE ....................................... 25/32"
FINE .......................................... 3/32"
LONGITUDINAL TABLE SPEED (HYDRAULIC) ... 0.6 - 240" IPM
TABLE SWIVELS ............................... 9 DEGREES
REVERSING DWELL ........................ 0 TO 5 SECONDS
1 GRADUATION OF FEED SCALE .................. 0.0002"
AUTOMATIC FEED, MAXIMUM ...................... 0.036"
AUTO. INFEED PER TABLE REVERSAL .. 0.00005" TO .0012"
INFEED FOR PLUNGE GRINDING ........ 0.00004" TO .002"
MICROMETER STOP, 1 GRADUATION .............. 0.00005"
UNIVERSAL GRINDING SPINDLE HEAD:
TRANSVERSE MOVEMENT OF WHEEL SLIDE .......... 11-1/4"
HYDRAULIC RAPID WHEEL SLIDE ADVANCE/RETRACTION
STROKE ................................... 1-37/64"
GRINDING WHEEL SPEEDS (4) 1500, 1700, 2200 & 3600 RPM
GRINDING WHEEL FOR CYLINDRICAL
GRINDING ............................ 16" X 2" X 5"
GRINDING WHEEL (SURFACE GRINDING) ... 10" X 3/4" X 3"
SWIVEL OF GRINDING HEAD W/LOCKING EVERY
90 DEGREES ............................ 270 DEGREES
VERTICAL MOTION OF GRINDING SPINDLE HEAD,
HEIGHT OF CENTERS ........... 4-59/64" TO 13-25/32"
INFINIT. VARIABLE SPINDLE SPEEDS ........ 10 - 400 RPM
WORKHEAD SWIVELS ........................ 360 DEGREES
INSIDE TAPER OF WORK SPINDLE ................... #5MT
APPROXIMATE FLOOR SPACE REQUIRED .... 106" X 64" X 66"H
APPROXIMATE MACHINE WEIGHT .................. 6,500 LBS
HYDRAULIC OPERATION FEATURING:
-INFINITELY VARIABLE TABLE TRAVERSE
-RAPID WHEEL ADVANCE & RETRACTION
ADJUSTABLE CENTER HEIGHT FEATURE W/MAXIMUM SWING 19.8"
DUAL LEFT-HAND & RIGHT-HAND WHEEL MOUNTING
MACHINE IS PRE-WIRED TO ACCEPT IN-PROCESS GAUGING SYSTEM
8" 3-JAW CHUCK, SWISS TYPE, BRAND UNKNOWN
MT.5 TAPER MOUNT WITH DRAW BAR
1) STANDARD TALE MOUNTED DIAMOND WHEEL DRESSER
1) SWIVELLING DERSSER WITH MICROMETER ADJUSTMENT
FOR EXTERNAL AND INTERNAL GRINDING
1) RADIUS DRESSER, TABLE MOUNTED, FOR CONVEX AND CONCAVE RADII
1) WHEEL HUB FOR 10" FACE GRINDING WHEELS
1) SWING AROUND ID ATTACHMENT, FACTORY MOUNTED ID BLOCK
1) FORTUNA ID SPINDLE, 20,000 RPM WITH 5 ARBORS,
1) SET OF 4" RISER BLOCKS FOR WHEELHEAD, WORKHEAD
& TAILSTOCK, ALLOWS FOR 17.8" MAXIMUM SWING
1) WHEEL BALANCING STAND WITH BALANCING ARBOR
LARGE AMOUNT OF GRINDING WHEELS, EXTERNAL & INTERNAL,
** EXCEPTIONAL CONDITION AND APPEARANCE **
