Mini skid steer hydraulic forklift attachment
What do you look for in equipment?
Versatility, Quality, Innovation. That s the challenge we accepted in developing the Forkster line of attachments. The Forkster s all terrain lifting chassis exponentially increases the stability and capacity of your loader, whatever it s size.
Unlimited lifting and hauling applications are presented with the unique technology behind the Forkster framework. Small enough to transport readily. Powerful enough to leave the big bulky equipment of yesteryear at home collecting dust!
How can my mini-skid handle loads greater than its own weight?
Using the Forkster lifting chassis increases lifting capacity up to 5 times that of a Mini-Skid! The Forkster can turn your Mini-Skid into a MIGHTY-SKID!
During the design process key aspects were closely monitored to achieve the following results:
The unique shape of the Forkster essentially centers the load over its 8-ply tires and High Strength / Low Alloy steel frame. This design keeps the load on the Forkster chassis and minimizes the mini-skid's load.
Moving heavy loads is made easy by the long caster arms provided. This allows for a minimal turning radius, keeping your mini-skid as nimble as ever. Typically, the Forkster can be operated with your mini-skid at half throttle. As with any attachment, traction is limited by the ground condition and grade.
The lifting ability of the Forkster is based on one of the strongest and oldest geometric designs - The Pyramid. Attaching the Forkster lengthens the overall wheelbase of the skid steer. By widening the Forkster wheel stance to 88", loads of 2,500 lbs can safely be handled* to the 8' lifting height the Forkster offers.
Application: Mini Skid Steer / Rubber Track Loaders
Wheel: 8 x 7.5bolt on 4.5" bolt circle
Clearance Height: 77" with forks lowered to 125" maximum
Clearance Width: 44" outside tires in innermost position, up to 88" extended
Overall Length: 32" from attachment receiver to front of tires
Hydraulic Spec: Min pressure: 1,500psi
Weight: 950 lbs. 48" Fork option
Capacity (Volume): 64" x 48" x 48"
Please be our guest and watch the 2508 Lifting System on YouTube:
http:// /watch?v=ds_HvHHmF48
(***)-880-6614 or (***) 271-3313
