9.8" Dia. MTI MT-1030-S2 WHEEL DRESSER, Machine Tool for Dressing Diamond Wheels
Used Manufacturing Technology Inc. (MTI)
Model MT-1030-S2 Diamond Wheel Truing Machine
Maximum Workpiece Diameter:......... 9.8"
Maximum Workpiece Length:........... 20"
Workhead Speed:..................... 0-330 rpm
Table Travel:....................... 20"
Spindle Power:...................... 5 HP
Spindle Speeds:..................... 1700, 2300 RPM @60Hz
Truing Wheel Diameter:.............. 16"
Infeed Travel:...................... 6"
Auto Infeed Increment:.............. .000050"-.0005"
Electrical:......................... 220 Volts, 3 phase, 50/60Hz
Total System Current Consumption:... 30 Amps
Machine Size:....................... 96" L x 56" W X 55" H, 4000 Lbs.
Micro Infeed with LED Display on Control Console
Front Enclosure with Window for Coolant
