> 9" x 12" dia x 23'-6" l stainlesss twin screw conveyor
9" x 12" dia x 23'-6" l stainlesss twin screw conveyor
9" X 12" DIA X 23'-6" L STAINLESSS TWIN SCREW CONVEYOR
STAINLESS STEEL MATERIAL CONTACT PARTS. FIRST SECTION HAS TWO 9" X 10' LONG STAINLESS STEEL TWIN SCREWS. CONVEYOR WAS USED AS A BIN UNLOADER AND FIRST SECTION OF FLIGHTING IS 4.5" PITCH FOR APPROX 6' AND THEN 9" SCREW PITCH CHANGES TO 9". FLIGHT THICKNESS ON SCREW IS 1/4". SCREW THEN CHANGES TO 12" DIA TWIN SCREWS APPROX 13' LONG. 12" SCREW IS ALSO VARIABLE PITCH WITH FIRST SECTION BEING AN 8" PITCH FOR APPROX 6' AND REMAINING SECTION BEING ON 12" PITCH. 12" STAINLESS STEEL FLIGHTING IS 5/16" THICK. TROUGH IS STAINLESS STEEL, FLANGED. DRIVE SHAFTS ARE 3" DIA. OUT IS 13" X 26" AND IS LOCATED ON DRIVE END.
