Clausing/colchestor 15 lathe instruction & parts manual
15-inch Geared Head Engine Lathes
This is a reproduction, not a photocopy, of an original Clausing 15 Lathes Instruction and Parts Manual. This manual covers the 15"x30" and 15"x48" heavy duty geared head engine lathes. This manual contains information on setup, lubrication, maintenance, and controls as well as a complete parts list. There are 22 pages on instructions that include accessories and the parts.
Installing...................................................
Lifting.......................................................
Cleaning and Bolting Down.......................
Electrical Wiring.......................................
Chuck Mounting.......................................
Lubrication...............................................
Drive Starting Stopping Reverse................
Headstock Speed Selection.......................
Swing Frame.............................................
Gearbox....................................................
Apron and Thread Cutting.........................
Setting up Gear Train.................................
Metric Thread Cutting................................
Saddle and Slides......................................
The Bed and Tailstock...............................
Equipment List with Ordering Codes..........
Coolant System.........................................
Square Turret Toolpost..............................
Steady Rest and Rear Toolpost..................
Feedstops.................................................
Rapid Threading Unit.................................
Telescopic Taper Attachment.....................
Hydraulic Profiling Unit..............................
Spares Lists............................................
