Hp agilent 1630D logic analyzer with 5 pods~option 007
Hewlett Packard Agilent 1630D Logic/NetworkAnalyzer
Used HP Logic Analyzer includes a set of five probes, two with leads, and comes with option 007. I have been unable to find a listing online of what 007 does. Serial No. 2511A04232.
According to a search for specs on the Internet, here are the main points about this unit:
The HP 1630 series of logic analyzers consists of 3 models designed to meet the needs of digital design and test engineers. The D model has 43 channels.
The HP 1630D facilitates hardware analysis and debug of 16-bit microprocessors. The HP 1630A's measurement capability is also available in the HP 1630D, but with additional state and timing channels to meet the needs of 16-bit microprocessors. Total channel count is increased to 43, where eight or 16 of the channels can be used for high-speed timing analysis. Glitch triggering and capture are also increased to eight channels.
In addition to triggering on channels from one to 16 channels wide, you can define a simultaneous occurrence of a pattern and positive or negative edge to assure data registration precisely on entering or exiting the specified pattern. You can also specify a pattern or a glitch on one or more channels. You can trigger on just edges or glitches, and you can define the valid pattern duration.
X and O cursors can be moved anywhere on or off screen. You can magnify the trace around either cursor for greater visual resolution. Time intervals are displayed on-screen, independent of magnification and sample period.
