Brown & sharpe 20X40 universal grinder no. 3 w/tooling
Brown & Sharpe 20x40 Universal Grinder No. 3 w/Tooling
* Professionally Rebuilt in 1996
* Traverse & plunge cut selection knob
* Table speed knob (0-150 ipm)
* Crossfeed start/stop toggle
* Crossffeed handwheel retraction button
* Headstock running, table running & off toggle
* Plunge feed rate dial (.0125 - .300 ipm)
* Dwell (L/R) dials (0-2.5 sec)
* Traverse crossfeed rate (L/R) dials (.0001-.003 per reversal)
* Lever control, w/headstock & w/headstock & table switch
* Headstock speed dial (25-500 rpm)
* Internal/external grind switch
* Includes headstock, footstock, truing fixtures
* Includes original Operation & Maintenance, Repair Parts & rebuild information, schematics & manuals
* Also includes various tooling & accessories (as shown)
* Power Requirements: 460V (AC) - 12.55A FLC - 60 Hz - 3 PH)
* Distance Between Centers: 40"
* Wheel Capacity: 14" diameter
* Turret Swivel: +/- 90 deg.
* Hole Through Spindle: 1-1/4"
* Spindle Taper: B&S No. 12 (1-3/4")
* Spindle Taper: B&S No. 10
* 5 HP - 208-220/440V - 14.6-14.0/7.0A
* 1/4 HP - 115V - 2.31A - 400/1200 RPM
* Franklin Electric coolant pump motor
* Lubrication tank capacity: 4 gal
* Hydraulic oil tank capacity: 15 gal
* Overall: L 137" x W 69" x H 76"
* Weight: 9,200 lbs (approx)
* Good - working at time of decommission
* Normal wear from previous use in working industrial shop environment
* Regular maintenance performed by previous owner
