New 50 ton scotchman 5014-tm ironworker
50 Ton Scotchman 5014-TM NEW IRONWORKER
SCOTCHMAN IRONWORKER, MODEL: 5014-TM
3" X 3" X 5/16" AND 2" X 2" X 1/4" AT 45 DEGREES
-BAR SHEAR CAPACITY 14" BLADES COMPLETE WITH 4 CUTTING EDGES
-BUILT IN NOTCHER, 2-1/2" X 3" X 5/16"
-TOOL TABLE WORK AREA FOR MOUNTING OPTIONAL TOOLING
-THREE 2" DIE HOLDERS, THREE JAM NUTS AND THREE STRIPPERS
-ELECTRICAL BOX SUPPLIED WITH EMERGENCY PALM BUTTON AND LOCK-OUT TAG-OUT ACCOMMODATIONS
-230/460 VOLT 3 PHASE ELECTRICS (MUST SPECIFY VOLTAGE)
-ALL GUARDS NECESSARY TO COMPLY WITH ANSI B 11-5 STANDARDS
CAPACITIES & SPECIFICATIONS RATED ON 65,000 PSI TENSILE, A 36 MILD STEEL:
THROAT DEPTH........................ 4"
PUNCHING CAPACITY................... 50 TON
SPECIAL TOOLING..................... 2-1/4" MAX. DIA.
FLAT BAR SHEER...................... 14" LENGTH
OPT. SOBER BLADE.................... 1/2" X 8"
ANGLE SHEAR 90...................... 3" X 3" X 5/16"
ANGLE SHEAR 45...................... 2" X 2" X 1/4"
LT. MATERIAL........................ 1/4" STROKE
HEAVY MATERIAL...................... 3/4" STROKE
TUBE SHEAR.......................... 1/2" TP 1", 16 GA.
PICKETT TOOL........................ 1/2", 3/4", 1"
ROD/ANGLE SHEAR COMBO............... 2" X 2" X 1/4"
ROUND............................... 3/4" MAX.
SQUARE.............................. 3/4" MAX.
90V NOTCHING........................ 6' X 6" X 1/8"
RECTANGLE NOTCHER................... 2-1/2" x 3" x 5/16"
PIPE NOTCHING................. 3/4", 1", 1-1/4", 1-1/2", 2"
BRAKE 8"...................... 24 TON
BRAKE 12"..................... 24 TON
HYDRAULICS.................... 1900 PSI
STANDARD...................... 230/460 3 HP 3 PH
OPTIONAL...................... 5 HP 230v 1 PH (add $345)
DIMENSIONS.................... W-24" L-60" H-66"
WEIGHT........................ 2,750 LBS
