16" swg 60" cc birmingham ndl-1660 special package engi
16" Swg 60" cc Birmingham NDL-1660 Special Package ENGI
16" Swing 60" Centers Birmingham NDL-1660 Special Package ENGINE LATHE, 6 HP, 12 Speed, 2-1/16" S
Model: NDL-1660 w/Removable Gap Block
Note: the photo shows this model
Attachment (including installation)
Hardened and ground gears and shafts
Oil bath lubricated headstock and gear box for smooth, quite operation
Induction hardened and ground bedways
12 spindle speeds, 32 - 2,000 RPM
Full length splash guard and foot brake
Wide range of feed and thread selections
Fully enclosed quick-change gear box
Large diameter leadscrew and feed rod
Equipped with chuck guard and tool post guard
Swing over cross slide: 8-1/4"
Spindle nose type (Camlock): D1-6
Spindle speed range: 32 - 2,000 RPM
Spindle center to bedway: 7-1/8"
Threads per inch (No.) range (TPI): (44) 2 - 56
Metric threads (No.) range (mm): (24) 0.5 - 14
Module threads (No.) range (mm): (24) 2 - 56
Diametral threads (No.) range (DP): (44) 0.5 - 14
Long. feeds (No.) range (in/rev): (18) 0.002 - 0.032
Cross feeds (No.) range (in/rev): (17) 0.0007 - 0.0095
Leadscrew diameter (in): 1-3/8"
Main drive: 6 hp, 2-Speed, 220V 3 ph Only
Maximum workpiece weight: 900 lbs.
Overall Dimensions: 109" L x 40" W x 50" H
8" 3 Jaw Chuck with top reversible jaws
Steady rest capacity 1-1/2" - 4"
Follow rest capacity 3-1/4" - 1-3/8"
12" Larger steady rest with roller jaws
5C Hand lever type collet closer "JFK" USA
DRO - Newall, Acu-Rite or Uniq
